Details

Sirius 2 Luminometer for Tubes

Intuitive luminescence reading

Sirius 2 LB 9526 is a compact and highly sensitive tube luminometer. Light collection is maximized through both the close proximity of the sample to the detector and the use of optimized light reflectors surrounding the sample vial. The luminometer is upgradeable with up to two injectors, making it perfect for flash assays, and can be equipped with an intuitive touch screen computer, enabling stand-alone operation. The Sirius 2 supports all basic luminescence technologies including flash-type Luminescence, glow-type Luminescence, bioluminescence and chemiluminescence.

HIGHLIGHTS

High performance luminescence detection

The Sirius 2 detects less than 0.5 zmol of firefly luciferase (1 amol ATP/tube). Light collection is maximized through the close proximity of the sample to the detector and the use of optimized light reflectors surrounding the sample vial. The detector is operated in photon counting mode, which ensures a very low background signal for excellent signal to noise ratio and the highest linearity.

Outstanding flexibility

The sample chamber is designed for performance and flexibility: from 35 mm petri dishes to microfuge format to 20 mL vials, just pick the sample format that fits your application best. The optional sample holders enable accurate injection into both, microcentrifuge tubes and standard luminescence tubes.

The system is compatible with a variety of sample formats:

Standard 12 mm luminescence tubes (55 and 75 mm)
Microcentrifuge tubes (1.5 and 2 mL)
Scintillation vials (up to 20 mL)
35 mm Petri dishes

Intuitive touchscreen operation

The touchscreen-driven software is very intuitive and operated by touch gestures. The easy-to-use software provides advanced features, such as handling of replicates, dual assay calculations, and display of graphics.

Data can be downloaded easily onto a USB stick or printed. The results can be exported for further calculation in Excel or other programs.

Automatic quickstart

Closing of the sample drawer automatically initiates the measurement. There´s no need to press any key. The automatic light shutter protects the detector from ambient light. This makes the system ready for measurement from the moment the door is closed. This means that there is no need to set a long delay before the measurement. This is necessary with most other tube luminometers so that the background can return to the initial level after the door has been opened

Flexible injector solutions

The system is available with up to two syringe-type automatic reagent injectors. The injection volume range is 20–500 μL. This very broad volume range allows the Sirius 2 to adapt to any assay using injectors. Ready-to go sample holders for precise injection are available for 1.5 ml and 2 ml microfuge tubes, as well as for 55 mm and 75 mm, 12 mm diameter tubes (standard format for most luminescence assays).

TECHNICAL DETAILS

Detectors	Low-noise photomultiplier tube in single photon counting mode
Detection technologies	Luminescence
Measurement modes	Endpoint, Kinetics, Multiple Kinetics
Spectral range luminescence	300-600 nm
Injectors	Up to 2 syringe injectors
Injector volume	20-500 µL
Tube formats	Luminescence tubes, 12 x 55 mm Luminescence tubes, 12 x 75 mm Microcentrifuge tubes, 1.5 and 2 mL
Luminescence sensitivity	<1 amol ATP/tube (ATP HS assay)
Dynamic range	6 orders of magnitude
Interface	Windows software, connected to computer by USB Optional integrated computer with built-in software
Display (integrated computer)	7” capacitive touch, gesture control, 480 x 800 pixels
External interfaces (integrated computer)	2x USB 2.0, 1x Ethernet (RJ-45)
Printer interface (integrated computer)	Network or USB printing (PCL6 or Postscript 3)
Data export	CSV (Excel), PDF, HTML formats
Available protocols	PC software: Quick Measurement included; additional options (purchased separately): Single Assay, Dual Assay, Single Kinetics, Multiple Kinetics, Cut-Off Built-in computer: Quick Measurement, Single Assay, Dual Assa
Power Supply	110-240 V, 24 V/2.5 A DC
Temperature tolerance	Storage: 0-40° C Operation: 15-35° C
Humidity tolerance	Storage: up to 80% non-condensing Operation: up to 70% non-condensing
Dimensions (W x D x H)	349 x 150 x 241 mm
Weight	3.6 kg

Informations complémentaires

Plus d’information
Format d'échantillon	12 x 75mm or 55mm tubes, 1.5 and 2ml microfuge tubes, 35mm culture dishes, liquid scintillation vials up to 20ml. Injection operation with 12 x 55 and 12 x 75mm tubes and 1.5 and 2.0ml Microfuge® tubes
Detecteur	PMT (tube photomultiplicateur) de comptage de photons, plage spectrale : 300–600 nm
Chambre de mesures	Retractable drawer with interchangeable reflectors and sample adapter
Sensibilité	Under 1,0 amol ATP
Plage dynamique (Linéarité)	6 ordres de grandeur
Injecteurs (Maximum)	0, 1, 2 (mise à niveau possible)
Volume d'injection	20–500 μl réglable par pas de 1 μl
Tubes	Chemically inert PTFE tubing and connections (PTFE or KEL-F)
Interface	Interface USB ou RS 232 pour connexion PC
Source de courant	Alimentation de bureau et cordon d'alimentation. 100–240 V CA, 24 V CC/2,5 A.
Plage de températures (°C)	Stockage : 0 - 40 °C Fonctionnement : 15 - 35 °C
Humidité	10 - 90 %, sans condensation.
Dimensions	45.6 x 34.9 x 15 cm/ 18 x 13.7 x 5.9 inch
Écran	7” capacitive touch, gesture control, 480 x 800 pixels
Fonctionnement autonome	Integrated computer with built-in software
Protocoles logiciels	Quick Measurement, Single Assay, Dual Assay and Wash & Prime protocol
Interfaces externes	2x USB 2.0, 1x Ethernet
Interface d'imprimante.	Network or USB printing (PCL6 or Postscript 3)
Exportation de données	By USB memory stick; CSV (Excel), PDF, HTML formats
