Centrifuge : SIGMA 3-16L (Last Call / Discontinuation)
Last Call / Discontinuation
SIGMA 3-16L (max 4 x 400 ml) (This product was discontinued and Replaced by Sigma 3-16T)
Excellence in universal middle-sized centrifuges
The properties of the Sigma 3‑16Lcompact benchtop centrifuge make it a classic all-rounder. This practically oriented laboratory centrifuge is appreciated for its outstanding capacity and wide variety of uses. Along with high performance and reliability, it features unmatched versatility. As a well-balanced all-purpose centrifuge with extensive rotor and accessory options, it is suitable for a very wide variety of tasks.
What makes the Sigma 3‑16L all-purpose centrifuge so attractive
The Sigma 3‑16L scores with impressive features: it is pleasantly quiet in use, and the patented one-knob controller and illuminated function keys make operation intuitive. Automatic lid opening can optionally be configured for easy end of run indication.
The centrifuge has an extraordinary capacity with a maximum of 4 x 400 ml. A broad selection of fixed-angle and swing-out rotors is available, along with an extensive range of accessories with buckets and adapters, including many biosafe configurations. The resulting compatibility with a large number of specimen tubes enables high versatility and allows use for a very wide variety of tasks, including high-throughput applications.
The centrifuge and rotors are optionally available with the g-lock system. This innovative rotor system enables quick and easy rotor exchange without tools.
| Max. capacity [ml] | |
|---|---|
| swing-out rotor | 4 x 400 |
| fixed-angle rotor | 6 x 94 |
| Max. RCF | 21.475 |
| Max. speed [rpm] | 15.300 |
| Min. speed [rpm] | 100 |
| Noise level at maximum speed (approximate) [dB(A)] | |
|---|---|
| fixed-angle rotor 12154 | ≤ 60 |
| swing-out rotor 11180 with bucket 13190 |
≤ 65 |
| Max. acceleration time [s] | |
| fixed-angle rotor 12154 | ≤ 25 |
| swing-out rotor 11180 with bucket 13190 |
≤ 20 |
| Max. braking time [s] | |
| fixed-angle rotor 12154 | ≤ 42 |
| swing-out rotor 11180 with bucket 13190 |
≤ 22 |
| Temperature setting range [°C] | - |
|---|---|
| Power consumption [W] | 500 |
| Height x Width x Depth [mm] | 355 x 460 x 600 |
| Height with open lid [mm] | 770 |
| Weight without rotor [kg] | 48 |
| Refrigerated | Non-Refrigerated |
|---|---|
| Capacity | 4 x 400ml |
| Temperature Range | N/A |
| Max. RCF [xg] | 21,475xg |
| Max. Speed [rpm] | 14,500 |
| Min. Speed [rpm] | 100 |
| Max. acceleration | ≤ 25 [sec.] (rotor #12154) |
| Max. deceleration | ≤ 42 [sec.] (rotor #12154) |
| Noise level at max speed [dB] | ≤ 60 dB(A) (rotor #12154) |
| Power Consumption [W] | 500 [W] |
| Power Supply | 120V, 60Hz |
| Height x Width x Depth [mm] | 355 x 460 x 600 [mm] |
| Height with open lid [mm] | 770 [mm] |
| Weight without rotor [kg] | 48 [kg] |
| Catalog Number | Product Name | Price | Qty |
|---|---|---|---|
| 70828 | Sigma Imbalance switch (3-16, 3-16K, 3-18, 3-18K) |
$185.00
|
|
| 70455 | Sigma Rotor Identification (2-16KCzent3, 2-16Kzent4, 3-15, 3-16, 4K-15, 6-15, 6K-15) |
$171.03
|
|
