Complete Thermostat Fermentation System for 5L Double Jacketed Air Lifter Vessel
Catalog Number:
FS-01-C054P-110/220V
Availability:
In stock
MBI Lab Equipment - Thermostat Lab Bioreactor- Air Lifter Vessel
The Thermostat system with Air lifter vessel is designed specifically for any cells or microbial sensitive to the shearing force. Hence with the skinny vessel design and the impeller-free agitation system. This bioreactor system is perfect for any photosynthetic culture and biofuel research that require extensive and high quality light source. Theunique agitator-free design also helps cells to circulate within the vessel without breaking their morphology.
- Micro-sparger and adjustable draft tube to facilitate water circulation and achieve high aeration efficiencies
- Single wall or double jacketed vessels available
- Color touch screen and graphical user interface for easy operation
- Real-time trend data recording ensures best fermentation performance
- 2-stage DO cascade for precise DO (dissolved oxygen) level control
- Ethernet remote control ability allows you to navigate and operate your fermentation process from your desktop
- No additional software required
- Quick connectors for easy operation
- 4 built-in assignable and programmable peristaltic pumps for automatic pH, antifoam and feeding control
- Automatic process allows you to set up your 15 steps programmable control
- Manual process allows you to run individual parameters independently
- Photobioreactor lighting module (optional) for your photosynthesis reaction
- Full accessories are offered as a standard package
MBI Fermentor
| Vessel Working volume (Liters) | 5 L |
|---|---|
| Vessel Total volume (Liters) | 6.8 L |
| Material | Borosilicate glass / 316L stainless steel for headplate and all fittings |
| Display | 10.4” Colorful touch-screen interface |
| PC interface | USB - ethernet - RS-485 |
| Methods | Up to 59,994 process programs |
| Dimensions | 400 x 500 x 740 mm / (15.75” x 19.69” x 29.13”) |
| Body material | ABS front panel and painted iron housing |
| Power | 110V / 220V; 50/60 Hz |
| Air flow | 0, 1 – 10 LPM |
| Temperature Control | Thermostat system; Built-in heat exchanger (400 W heater/water circulation pump); Automatic cooling water valve |
| Temperature range (°C) | +5ºC to +60ºC |
| Temperature Resolution | 0.1C |
| Temperature sensor | Platinum RTD probe (Pt 100) |
| Temperature Program control (℃/℉) | Programmable 15 steps PID control |
| pH | 2 - 14 |
| Readability pH | 0.01 |
| pH Probe | Gel-filled electrode; Autoclavable |
| pH Control mode | Manual/ Acid Start/ Programmable 15 steps PID control with adjustable deadband |
| Dissolved Oxygen range | 0 – 200% |
| Dissolved Oxygen resolution | 0.1% |
| Dissolved Oxygen probe | Polarographic DO sensor; Autoclavable |
| Dissolved Oxygen Control Mode | Cascade function to response to a. Increase or decrease agitation speed b. Oxygen enrichment module (optional) c. Start substrate feeding program |
| ORP Measurement Range | -/+ 2000 mV |
| ORP Resolution | 1 mV |
| ORP Probe | Gel-filled electrode; Autoclavable (optional) |
| Foam Probe | 316L stainless steel protector with insulated teflon tube; On/Off control |
| Peristaltic pumps | 4 Built-in pumps; One external pump (optional, RS-485 interface with relay output) |
| Peristaltic pump motor type | Precise stepping motor; minimum speed is 1 rpm |
| Peristaltic Pump Speed Range | 0 – 65 rpm |
| Peristaltic Pump Speed Increment | 1 rpm |
| Peristaltic Pump Control mode | Manual or Programmable 15 steps feeding control;Pump can be assigned for Acid, Base, Antifoam and Substrate |
| Exhaust Device type | 316L stainless steel condenser |
| Requirements | Air 1 Bar maximum, must be dry, oil-free and filtered (14.5 psi), Autoclave For sterilization, Power supply 100-120V 50/60Hz or 210-230V 50/60Hz with electrical safety cutoff switch, Water 2 Bar maximum (29 psi) |
