EZ Read 800 Research Microplate Reader (Discontinued)

Catalog Number:
80-4002-01
Availability: Out of stock
Please contact us

***Discontinued by manufacturer***





________________________________________________________________________________

Biochrom - EZ Read 800 Research Microplate Reader

The EZ Read 800 is a fast and accurate microplate reader that is an ideal choice to keep up with a heavy workload in a busy high-throughput laboratory. The EZ Read 800 microplate readers are PC-controlled using new, intuitive Galapagos software.  EZ Read 800 comes in two applications focused models: the EZ Read 800 ELISA is a dedicated ELISA reader, the EZ Read 800 Research offers versatilty by extending its applications capacity to measuring total protein and cell proliferation assays in additional to ELISA assays.

Galapagos for EZ Read Software's ‘click and drag' approach makes usability a key feature.

  • Create new plate layouts
  • Add multiple assays to a plate
  • Add multiple plates per analysis
  • Easy to create new methods.
  • Select only the data you want for data reporting
  • Windows 7 & 8 compatibility as well as older Windows OS from XP.
  • So easy you won't need to export your data into Excel.

EZ Read 800 ELISA and EZ Read 800 Research

  • >5 second for 96-well plate
  • Measures flat, u-bottom and v-bottom plate with standard ANSI/SBS footprint.
  • Four modes of shaking for complete mixing of solutions and more reproducible results.
  • Automatic lamp calibration ensures measurement performance.
  • USB 2.0 PC connection

Two versions for specific applications requirements:

Biochrom EZ Read 800 ELISA microplate reader comes with 4 filters that can be used to measure most ELISA assays:

ELISA Assay Substrate

Filter
NPP, ABTS 405nm
OPD 492nm
Slow TMB, Turbo TMB, Ultra TMB 450nm
Reference wavelength 620nm

Biochrom EZ Read 800 Research microplate reader comes with filters that can be used to measure ELISA, total protein and cell proliferation assays.(405, 450, 492, 562, 570, 595, 620, 650nm)

More Information
Light Source Tungsten halogen lamp
Measurement range 0.000…4.000 OD
Precision 0.5% 0.1-2.5 OD
Accuracy 1% : 0.100 - 2.5 OD
Standard filters 405, 450, 492, 562, 595 & 620nm
Wavelength Selection Filters
Wavelength range 400 - 750nm
Photometric Method Transmission photometer
Detector Single channel silicon photodiode
Reading Speed 5 Seconds
Shaking 4 modes
Optical system Filters
Plate types 96 well plate (flat, round and v-bottomed well formats)
Resolution 0.001OD
Linearity (±) <±0.25% and ±0.0025 OD from 0.1 OD to 2.5 OD at 492 nm
Data Output USB 2.0
Reproducibility ±0.02 °C
Quality control Autocalibration, autolamp adjustment, status report
Validation Optional check plate
Dimensions 360x515x315 mm
Net Weight 10.4 Kg
Temperature Control -
Computer Interface USB 2.0
Power 90-250V, 50/60 Hz, 80VA
Power Supply Voltage rating: 100VAC - 240 VAC; current rating: 50 /60 Hz, 1.5A
PC Operation Yes
Software Galapagos Software
