Microplate Washer - Atlantis Anthos Fluido4 Microplate Washer (Discontinued)
***Discontinued by manufacturer***
________________________________________________________________________________
Asys, Biochrom
Flexibility and precision in microplate washing
The Atlantis microplate washer is renowned for its excellent price/performance ratio. Equipped with features usually only available as optional extras, the Atlantis is the ultimate choice for discerning laboratories. Operation is simple, with the two line alphanumeric display and 5 soft keys for easy programming; the Atlantis allows up to 50 wash programmes and 20 plate types to be permanently stored.
In addition, the plate carrier is detachable for cleaning and the quick changing of manifolds simplifies the use for different plate types The unique manifold position sensor allows a precise height adjustment which minimises residual volumes. Digitally controlled aspiration and dispensing pumps provide high accuracy and low noise levels.
Features
- Top loading
- Easy automation; very user friendly, plate fully visible during washing process
- Multilingual operation dialogue
- The Atlantis microplate washer speaks your language
- Protection against outrunning liquids
- Splash-proof housing protects the washer
- Low noise level because of electronic controlled aspiration and dispensing pump
- Quiet aspiration pump instead of a noisy vacuum pump ensures pleasant working conditions
- No more pressurized or tight bottles necessary
- Easy programming and operation
- User friendly menu on a 2×16 alphanumeric display combined with 5 soft keys for easy programming
- Up to 50 wash programs and 20 different plate types can be permanently stored
- Simplified maintenance
- Detachable plate carrier, easy cleaning and disinfection, quick change of manifolds
- Improved safety functions
- Manifold position detection for plate bottom sensing
- Liquid level sensors in wash- and waste bottles optional available
- Automated rinsing
- Eliminates problems, such as clogged wash heads, caused by improper or missed maintenance
| Wash Programs | Up to 50 |
|---|---|
| Wash Cycles | Up to 20 |
| Plate types | 96 well plate (flat, round and v-bottomed well formats) |
| Wash Liquid Channels | 1 × washbuffer 1 × rinse liquid Up to 4 liquids optional |
| Dispensing Volume | 50 to 2000μL in 50μL increments |
| Dispensing inaccuracy | Below 5% at 300 μL |
| Liquid Flow Rate And Aspiration Strength | Programmable |
| Residual Volume Per Well | Below 1.5μL |
| Aspiration Time | 0…10s |
| Soak Time | Up to 1000s |
| Shake Time | 0…10s |
| Shaker Speed | Software adjustable |
| Manifold Options | 1 × 8 channels 1 × 12 channels 1 × 16 channels (for 384-well plates) |
| Standard Bottle Set | 3 × 2l (wash) 1 × 2l (rinse) 1 × 2.5l (waste) |
| External Computer Interface | RS-232 |
