Photopette® Turbidity - Handheld Turbidimeter (supports 570 nm, 850 nm)
Catalog Number:
508 PT
Availability: In stock
$2,832.90
Photopette® Turbidity (supports 570 nm, 850 nm)
Handheld Turbidimeter
- Geo-tagging Embedded in Measurement Data
- Measure Anywhere & Directly in the Sample
- Sample Documentation Via Camera
- Compliant to USEPA 180.1 and ISO 7027
- Export Data as CSV File to Cloud Server Or via E-Mail
Photopette® Turbidity is an easy-to-use turbidimeter dedicated for measurements at 570 nm and 850 nm and compliant to USEPA 180.1 and ISO 7027. It's ideal for environmental monitoring, at the wastewater treatment plant and for food & beverage industry.
The Photopette® is battery powered and has a small footprint, which makes the instrument highly portable and able to use anywhere in the field or the laboratory.
Photopette® App
Key Features
- GPS, Photo, Notes, Date/Time Embedded in Data Files
- Google Maps Overlay of Data
- Inbuilt Applications/Calibrations
- 'Method Maker' Feature for Custom User Calibrations
- Data Export as CSV file Via E-Mail or Cloud
Technical Specifications
| Wavelengths | 570 nm, 850 nm |
| Wavelength Accuracy | ±2 nm |
| Measurement Precision & Accuracy |
±0.003 AU |
| Photometric range | 0.000 AU ~ 3.000 AU |
| Measurement time | Within 2 seconds per measured wavelength |
| Warm up time | None |
| Lifetime (light-source) | >500,000 measurements per wavelength |
| Operation and handling | • Easy sterilization with ethanol wipes. • Water and dust resistant housing. • Resistant to mild acids and solvents. |
| Operating conditions | • Recommended: 18~25 °C at 30% RH. • Maximum: 5~45 °C at 80% RH (non-condensing). • (25,000 measurements and / or 6 days standby on a single charge). • Auto power save mode. |
| Storage conditions | -20 to 50 °C (max) and up to 80% RH (non-condensing). |
| Disposable CuveTip® | Standard CuveTip®; UV CuveTip® Chemical compatible to aqueous solutions, dilute acids and bases, alcohols, vegetable oils, blood serum, cell culture media, etc. |
| Permanent metal attachment CuveTip® |
UV to visible range. *Highly accurate. Can be sterilized in 70% ethanol. Chemical compatible to most organic solvents, dilute acids and bases, mineral and vegetable oils, blood serum, cell culture media, etc. |
| Software | App running under Android and iOS, simple and intuitive to use. Factory defined applications; user defined applications generated with the Method Maker” function. Automatic kinetic measurements, seamless connectivity and data sharing within seconds. Geo tagging, photo, notes, date and time embedded in data files. Automatic software and firmware updates. Self-testing function. |
| Power supply | Internal 2500 mAh lithium-ion battery with microUSB charging socket. |
| Dimensions and weight | Fits within 150 mm x 47 mm x 42 mm; Weight = 160 g approx. |
| Supported languages (App) | English, German and Chinese. |
| Certification | CE and FCC by TÜV SÜD Singapore. |
| Spectrophotometer type | UV / Visible |
|---|---|
| Wavelength range | 570nm, 850nm |
| Wavelength Accuracy | ± 2nm |
| Photometric Range | 0.000 -> 3.000 AU |
| Photometric accuracy | ±0.003 AU |
| Regulatory Compliance | CE and FCC by TÜV SÜD Singapore. |
| Software Languages (on-board software) | English, German and Chinese. |
| Net Weight | 160 g approx |
| Dimensions | Fits within 150 mm x 47 mm x 42 mm |
| Software | App running under Android and iOS, simple and intuitive to use. Factory defined applications, user defined applications generated with the Method Maker” function. Automatic kinetic measurements, seamless connectivity and data sharing within seconds. Geo t |
| Measurement time | Within 2s per measured wavelength |
