Intuitive touch screen LCD controller with easy icons and logical menus
•
Automatic run is available with non-volatile set point memory after power interruption
•
Built-in RS-232 port and USB port for external control and data collection
Shaking Control
•
Speed range: 10 to 500 rpm (10 to 250 rpm for the top unit of a stack)
•
Orbit diameter: 19.1 mm
•
Timer range: 1 min. to 999 hr 59 min
•
Audible/Visible alarm activated by shaking speed deviation
•
Worry-free operation: Automatic shaking speed adjustment in case of excessive workload such as unbalanced load placement, unusual vibrations caused from unstable floor or external shock
•
Shaker protection system against over-current, stalled platform check
Temperature Control
•
Temperature range:
Amb. +5°C to 80°C (for ISS-3075 / 4075) Amb. -20°C (Min. +4°C) to 80°C (for ISS-3075R / 4075R)
•
Microprocessor PID control and auto-tuning
•
Three point temperature calibration
•
Triple independent temperature monitor system:
• Temperature deviation alarm (High/Low)
• Electronic temperature limiter (High/Low)
• Mechanical over-temperature limiter (High)
* Temp. change may occur during automatic defrost (for ISS-3075R/4075R)
Constructional Features
•
Stackable design: Chambers stackable up to two levels
•
Wide speed range even with heavy workload: Equipped with a maintenance-free BLDC motor to generate smooth, quiet, uniform, and yet powerful shaking motion
•
Repetitive task capability: Platform stops where it starts - highly beneficial for automated dosing or sampling process
•
Pleasant test environment: Smooth acceleration and deceleration control prevents chemical spills from flasks or test tubes
•
Wide sample monitoring: Clear observation of samples without affecting inner chamber's environment thanks to the transparent viewing window with bright LED lamps
•
Easy-access drain system with a quick disconnect valve offers great convenience to clean up of spills
•
Two adjustable-height shelves provided allow static incubation or refrigeration, which increase storage capacity
•
Air-tight silicone door seal to provide excellent temperature uniformity
•
Corrosion resistance stainless steel interior
•
Three step adjustable high-velocity fan ensuring uniform temperature distribution and rapid thermal recovery after door open
•
Retractable foot caster, beneficial for easy mobility during installation or relocation (optional)
•
Built-in electrical outlet with a safety cover inside the chamber
