DuoSeal 1374 High Vacuum Pump
Catalog Number:
DuoSeal 1374
Availability: In stock
Product Details
- High contamination tolerance
- Ultimate vacuum <0.001 Torr
- Low RPM for long service life
DuoSeal Vacuum Pumps are known for their ruggedness world-wide. These pumps have large oil reservoirs to dilute contaminants. Low pump rpm to reduces friction and wear while minimizing reservoir temperature to lessen chemical reactivity. Pump can be ordered with an optional exhaust filter to control oil mist.
| 1 x 10-4 torr | |
| 231 lb. | |
| 8.8 A | |
| 510 rpm | |
| 1374 | |
| 100 kg | |
| 60 Hz | |
| 47.6 cm | |
| 66 cm | |
| High Vacuum Pump, Two-Stage | |
| 1 x 10-4 torr |
| 1.5 hp | |
| 105 kg | |
| V-belts, pulleys, belt guard, Oil supply, N. American 115V Plug | |
| 115/230 V 60 Hz | |
| 231 lb. | |
| 23 CFM | |
| 18.75 in. | |
| 26 in. | |
| 13.7 in. | |
| Concentrating and Degassing, Freeze Drying, Schlenk Drying Lines, Schlenk drying lines, freeze drying, vacuum distillations, concentrating and degassing, Vacuum Distillations | |
| 115/230 V |
| Applications | Vacuum Ovens, Glove Boxes, General Laboratory Vacuum |
|---|---|
| Type | Belt-Drive Vacuum Pump |
| Free Air Displacement CFM (l/min.) @60Hz | 23(650) |
| Ultimate Pressure | 1 x 10-4(0.00013) |
| Pump RPM | 510 |
| OIl Capacity | 1.25(1.2) |
| Motor Horsepower (watts) | 1-1/2(1120) |
| Adjustable Vac. / Gas Ballast | Yes |
| Tubing Needed | 1-5/8(41) |
| Intake Thread NPT | 1 3/4 - 20 straight thread |
| Exhaust Thread NPT | 1 3/4 - 20 straight thread |
| Overall Dimensions LxWxH in. (cm) | 26x13.7x18.8 (66x34.8x47.6) |
