IKA Viscometer ROTAVISC me-vi Complete
ROTAVISC me-vi Complete
The new ROTAVISC series determines the viscosity of liquids in all areas of application ranging from the laboratory to quality control. The four devices measure in different viscosity ranges. Regardless of a simple or demanding viscosity measurement - the ROTAVISC delivers rapid and accurate results. The scope of delivery includes a standard spindle set ( SP7- SP12), a protective bracket, temperature sensor, quick connector, hook connector and ROTASTAND stand.
Easy to operate: The generous 4.3″ TFT display allows for an intuitive menu guidance. A digital spirit level also supports the correct set-up of the start-up condition. The simple ramp function simplifies repetitive tasks.
Highest measurement accuracy: The level of measurement accuracy of the ROTAVISC rotational viscometer for both Newtonian and non-Newtonian fluids is +/- 1 % of the measuring range. The reproducibility is +/- 0.2 %.
Stepless speed: ROTAVISC is a viscometer, which offers stepless speed adjustment.
IKA Rotavisc me-vi Complete: Viscosity measuring range: 100 - 40.000.000 mPas
| Viscosity Measuring Range | 40,000,000 mPas |
|---|---|
| Viscosity Accuracy (FSR) | 1 % |
| Viscosity Repeatability (FSR) | 0.2% |
| Spring Torque | 0.7187 mNm |
| Guard Rail | me-vi |
| Measuring Spindle Series | SP set-2 |
| Overload Protection | Yes |
| Speed Range | 0.01 - 200 RPM |
| Setting Accuracy Speed | 0.01 ±rpm |
| Torque Display | Yes |
| Timer | Yes |
| Time Setting Range | 0.017 - 6000 min |
| Temperature Measurement Resolution | 0.1 K |
| Connection for Ext. Temperature Sensor | PT 100 |
| Permitted Density | 9999 kg/dm3 |
| Working Temperature Range(℃/℉) | -100°C to 300°C |
| Support Rod Diameter (with integrated fastening on stand) | 16 mm |
| Telescope Stand Stroke | 200 mm |
| Plug-in Coupling (Ø) | 12 mm |
| Basic Container Volume | 600 ml |
| Stroke Max. | 200 mm |
| Diameter | 16 mm |
| Dynamic Load | 5 kg |
| Dimensions | (W x H x D) 351 x 629 x 372 mm |
| Net Weight | 7.1 kg (15.6 lbs) |
| Permissible ambient temperature (℃) | 0°C to 40°C |
| USB Interface | Yes |
| Voltage | 100 - 240 V |
| Frequency | 50/60 Hz |
| Power Input | 24 W |
| Current Consumption | 1,000 mA |
