RV 3 V (Manual Lift)
Catalog Number:
0010003491
Availability: In stock
RV 3 V
The rotary evaporator RV 3 is the ideal entry-level model of the IKA rotary evaporator portfolio. It finds a multitude of uses in the chemical, pharmaceutical, and biotechnology industries, in research and development, in manufacturing and quality assurance, in laboratories, and in plant construction. Thanks to specially designed glass guides, the condenser makes extremely efficient use of the 1600 cm² cooling surface.
- heating bath with 4 l volume for up to 99 °C
- water heating bath with digital temperature display and carrying handles
- mechanical lift end-point safety stop
- locking mechanism: red indicator shows unlocked position of the vapor tube
- manual lift for precise positioning of the glassware
- adjustable immersion angle
- single-handed manual lift handling, suitable for left and right-handed operators
- stepless speed setting with dial control and speed display
- speed range: 20-300rpm
- low device voltage (24V) ensures user safety
- flask clamping mechanism with integrated push-off function for easy exchange of evaporation flasks
- high-efficiency condenser with 1600 cm² cooling surface - low space requirements
- compatible with the entire range of IKA RV 10 glassware
Scope of delivery
- RV 3 eco drive
- HB eco S099
- RV 10.900 Glassware vertical
- RV 10.73 Vapor tube (NS 24/40)
- RV 10.8001 Seal
Technical Data
| Type of cooling | vertical |
| Cooling surface | 1600 cm2 |
| Motor principle | DC |
| Speed range | 20 - 300 rpm |
| Speed tolerance set rotation speed < 100rpm | ±1 rpm |
| Speed tolerance set rotation speed > 100rpm | ±1 % |
| Lift | manual |
| Stroke | 150 mm |
| Heating temperature range | room temp. - 99 °C |
| Dimensions (W x H x D) | 440 x 530 x 330 mm |
| Weight | 28.3 kg |
| Permissible ambient temperature | 5 - 40 °C |
| Permissible relative humidity | 80 % |
| Protection class according to DIN EN 60529 | IP 20 |
| Voltage | 100 - 240 V |
| Frequency | 50/60 Hz |
| Power input | 1400 W |
| Cooling System Type | Vertical |
|---|---|
| Cooling surface | 1600 cm2 |
| Drive Motor | Brushless D.C Motor |
| Reversible direction of rotation | Yes |
| Lift | Manual |
| Stroke | 150 mm |
| Speed Range | 20 - 300 RPM |
| Speed tolerance set rotation speed < 100rpm | ±1 rpm |
| Speed tolerance set rotation speed > 100rpm | ±1 % |
| Temperature range (°C) | Ambient to 99°C |
| Heating bath temperature range | room temp. - 99 °C |
| Dimensions without glassware | 440 x 530 x 330 mm |
| Ambient Operating Range | 5 - 40°C |
| Permissible relative humidity (%) | 80% |
| Weight of evaporator incl. heating bath without glass parts | 28.3 kg |
| Protection class DIN EN 60529 | IP20 |
| Rated voltages | 100 - 240 V |
| Frequency | 50 - 60 Hz |
| power consumption [W] | 1400 W |
