Operating Features

General Control

• Intuitive touch screen LCD controller with easy icons and logical menus.
• Automatic run is available with non-volatile set point memory after power interruption.
• Built-in RS-232 port and USB port for external control and data collection.

Shaking Control

• Speed range: 30 to 500 rpm.
• Orbit diameter: 25.4mm for ISF-7100/R | 50.8mm for ISF-7200/R
• Timer range: 1 min. to 999 hr 59 min.
• Audible/Visible alarm activated by shaking speed deviation.
• Worry-free operation with automatic shaking speed adjustment in case of excessive workload.
• Shaker protection system against over-current.

Temperature Control

• Temperature deviation alarm (High/Low)
• Electronic temperature limiter (High/Low)
• Mechanical over-temperature limiter (High)

※ Temp. change may occur during automatic defrost (for ISF-7100R-7200R)

Constructional Features

• Wide speed range even with heavy workload.
• Repetitive task can be easily performed as the platform stops where it starts.
• Smooth acceleration and deceleration control prevents chemical spills.
• Clear observation of samples with transparent top viewing window and bright LED lamps.
• Inclined lid design for easy loading and unloading.
• Gas spring lid supports for soft opening and closing.
• Easy-access drain system with quick disconnect valve.
• Air-tight silicone door seal with lockable door for safe storage.
• Corrosion resistance stainless steel interior.
• Three step adjustable high-velocity fan ensuring uniform temperature distribution.
• Sturdy foot caster for easy mobility.
• Environment-friendly CFC-free refrigerant (for ISF-7100R / 7200R).

Technical Specifications
